Biasing of Transistor in Class A Operation (AE 294 )

Objective : To study the effect of biasing network of output signal and calculation on current gain and Frequency response for proper biasing network in class ‘A’ operation.

Features : Instrument comprises of DC Regulated protected Power Supply, one moving coil Round meter, 3 different values of RL and RE selectable using band switch provided on front panel, Circuit diagram is printed.
