Study of Gunn Diode Microwave Test Bench

Study of Gunn Diode Microwave Test Bench

Product Details:

X

Study of Gunn Diode Microwave Test Bench Price And Quantity

  • 1 Unit

Study of Gunn Diode Microwave Test Bench Trade Information

  • 5 Unit Per Week
  • 4-5 Days
  • Australia North America South America Eastern Europe Western Europe Middle East Central America Asia Africa
  • All India

Product Description

Study of Gunn Diode Microwave Test Bench

Experiments:
1. To study the characteristics of Gunn Diode.
2. To study the frequency, guide wavelength & free space wavelength.
3. To measure SWR & reflection coefficient.
4. To measure impedance of a load.

Components Name

Qty.

 Components Name

 Qty.

Gunn Power Supply

1

Gunn Mount

1

Pin Modulator

1

  Isolator

1

Frequency Meter

1

Variable Attenuator

1

Slotted Section

1

Tunable Probe

1

Detector Mount

1

Movable Short

1

Matched Termination

1

VSWR meter solid state

1

Wave Guide Stands

4

SS Tuner

1

BNC Cable

3

  Cooling Fan

1

Fixed Short

1
