8051 MICROCONTROLLER TRAINING KIT WITH LCD DISPLAY& IN-BUILT POWER SUPPLY

Name: 8051 MICROCONTROLLER TRAINING KIT WITH LCD DISPLAY& IN-BUILT POWER SUPPLY
Brand: AMBALA ELECTRONIC INSTRUMENTS
Price: 7500 INR
Availability: InStock

7500 INR/Piece

Get a Price/Quote

Product Details:

Display 16x2 Alphanumeric LCD module
Power In-built regulated power supply, 5V DC output
Voltage Input: 230V AC, 50Hz; Output: 5V DC regulated for 8051 circuit
Usage Educational, laboratory, and student training for embedded system design
Product Type Microcontroller Training Kit
Material High-grade PCB, durable ABS enclosure with silk screen printing
Design User-friendly front panel with systematic layout, onboard components, and labeled I/O
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

8051 MICROCONTROLLER TRAINING KIT WITH LCD DISPLAY& IN-BUILT POWER SUPPLY Price And Quantity

Minimum Order Quantity 1 Piece
Price 7500 INR/Piece

8051 MICROCONTROLLER TRAINING KIT WITH LCD DISPLAY& IN-BUILT POWER SUPPLY Product Specifications

Usage Educational, laboratory, and student training for embedded system design
Dimension (L*W*H) Approx. 330 mm x 230 mm x 75 mm
Illuminant LCD with backlight
Power In-built regulated power supply, 5V DC output
Design User-friendly front panel with systematic layout, onboard components, and labeled I/O
Voltage Input: 230V AC, 50Hz; Output: 5V DC regulated for 8051 circuit
Material High-grade PCB, durable ABS enclosure with silk screen printing
Power Source AC mains with in-built power supply
Accuracy High precision digital interfacing for microcontroller training applications
Weight Approx. 2.5 kg
Display 16x2 Alphanumeric LCD module
Charging Time Not applicable (operates on in-built regulated supply)
Product Type Microcontroller Training Kit

Operating Temperature 0C to 50C
Programming Interface On-board programmer with USB serial and parallel port options
Included Accessories User manual, patch cords, power cable, and sample codes
Fuse/Protection In-built overvoltage and short-circuit protection
Expansion Slots Provided for additional interface cards such as stepper motor, ADC, DAC
I/O Ports All I/O ports of 8051 are brought out to connectors for interfacing
Switches and Indicators Tactile keypad (matrix/type), Reset switch, and status LEDs
Peripheral Support Compatible with LCD, Keyboard, Relay, Buzzer, Seven Segment Display modules
Compatibility Supports in-system programming and external programmer
Memory Options On-board EEPROM and RAM for program/data storage
PCB Quality FR4 epoxy grade, solder mask with printed component layout
Connectivity RS232 serial port and separate extension connector
Microcontroller Supported Compatible with 8051 AT89S52 or equivalent DIP40 devices

8051 MICROCONTROLLER TRAINING KIT WITH LCD DISPLAY& IN-BUILT POWER SUPPLY Trade Information

Main Export Market(s) Asia, Central America, South America, Middle East, Africa
Main Domestic Market All India

Product Description

8051 MICROCONTROLLER TRAINING KIT WITH LCD DISPLAY& IN-BUILT POWER SUPPLY

Based on 8051/89C52 microcontroller

On board 32K RAM.

Battery backup for RAM area

64 K bytes of EPROM with powerful monitor program

48 I/O lines using 2 Nos. of 8255

3 channel programmable timer/counter using 8253

Two external interrupts INT0 & INT1 from CPU

20 x 2 LCD (Liquid Crystal Display) is provided for display

IBM PC compatible keyboard for entering the program, editing and executing the programs.

RS-232C interface using 8251

One serial USART interface provided by 89C51/89C52

All data, address and control signals (TTL compatible) available at FRC connector

Powerful software commands like INSERT, DELETE, BLOCK MOVE, SET/CLEAR BREAK POINT, SINGLE STEP, EXAMINE REGISTER, EXECUTE, EXAMINE/MODIFY MEMORY etc.

Enclosed in an attractive ABS Plastic cabinet with cover

In-built Power supply

User's Manual

Comprehensive Microcontroller Training Platform

Specifically designed to support 8051 AT89S52 and similar microcontrollers, this training kit offers students and trainees practical exposure to all relevant hardware interfaces. The front panel is systematically laid out with clearly labeled connectors and switches, supporting rapid learning and experimentation with real-world applications.

Flexible Connectivity and Expansion

The kit features extensive input/output options, including USB serial, parallel port, and RS232 connectivity. All microcontroller I/O ports are accessible via connectors, while expansion slots are available for additional modules such as ADCs, relays, keypads, and displays, making it suitable for advanced embedded project development.

User-Safe and Robust Construction

Engineered with an FR4 epoxy grade PCB and housed in a sturdy ABS enclosure, the kit includes vital safety mechanisms like in-built overvoltage and short-circuit protection. The high-precision design ensures reliable operation, while the included user manual, sample codes, and accessories simplify setup and ongoing use.

FAQ's of 8051 MICROCONTROLLER TRAINING KIT WITH LCD DISPLAY& IN-BUILT POWER SUPPLY:

Q: How do I program the 8051 microcontroller using the training kit?

A: The kit is equipped with an onboard programmer, providing both USB serial and parallel port interfaces. You can connect your computer using either port to upload programs directly into the 8051 or AT89S52 microcontroller. Sample codes and a user manual guide you through the programming process.

Q: What peripherals and modules are supported by this training kit?

A: This training platform supports a wide range of peripherals, including LCD displays, matrix or type keypads, relays, buzzers, seven-segment displays, and expansion cards for stepper motors, ADC, DAC, and memory. All I/O ports are accessible, making hardware interfacing straightforward for learners.

Q: Where can this training kit be used effectively?

A: The kit is ideal for engineering students, trainers, and laboratory environments. Its user-friendly design and systematic layout make it suitable for academic coursework, embedded system laboratories, and professional skill development in embedded design.

Q: What protection and safety features does the kit offer?

A: The training kit integrates overvoltage and short-circuit protection, safeguarding both the users and the equipment during experiments. A robust fuse system and regulated 5V DC output ensure safe and stable operation throughout training sessions.

Q: Why is this kit beneficial for embedded system learning?

A: With all essential microcontroller features brought out via connectors, a readable LCD, input keypads, status indicators, and expansion capabilities, the kit offers comprehensive hands-on experience. Learners gain practical skills in programming, interfacing, and troubleshooting embedded hardware.

Q: How is program and data storage managed on this kit?

A: The platform includes on-board EEPROM and RAM, facilitating reliable storage for user programs and data during operation. These features help users test, verify, and iterate embedded applications without concerning about data loss.

Q: What is included with the 8051 Microcontroller Training Kit package?

A: The kit package contains the main training unit, a user manual, patch cords, power cable, and sample codes. These accessories enable immediate setup and provide helpful resources for effective learning and experimentation.
