Magnetic Amplifier Trainer Series & Parallel

Get a Price/Quote

Product Details:

Power 230V AC, 50Hz
Display Analog Meter
Usage Educational/Test Bench for Magnetic Amplifier Experiments
Voltage 230V AC input
Product Type Magnetic Amplifier Trainer Series & Parallel
Material Mild Steel Body with Powder Coating
Design Compact Modular Panel
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Magnetic Amplifier Trainer Series & Parallel Price And Quantity

Minimum Order Quantity 1 Unit

Frequency 50 Hz
Terminals Banana Sockets for Easy Connections
Included Accessories Connecting Wires, Instruction Manual
Controls Potentiometers for Input Adjustment
Learning Modules Parallel and Series Magnetic Amplifier Experiments
Safety Fuse Protected
Load Type Lamp Load Included
Indicating Lamps Fitted for Operation Confirmation
Front Panel Diagrammatic Circuit Layout for Easy Learning
Environment Suitable for Laboratory and Training Institutes

Magnetic Amplifier Trainer Series & Parallel Product Specifications

Power 230V AC, 50Hz
Power Source Electric
Accuracy High
Design Compact Modular Panel
Display Analog Meter
Dimension (L*W*H) 410 x 320 x 110 mm
Material Mild Steel Body with Powder Coating
Usage Educational/Test Bench for Magnetic Amplifier Experiments
Weight Approx. 7 kg
Voltage 230V AC input
Product Type Magnetic Amplifier Trainer Series & Parallel

Frequency 50 Hz
Terminals Banana Sockets for Easy Connections
Included Accessories Connecting Wires, Instruction Manual
Controls Potentiometers for Input Adjustment
Learning Modules Parallel and Series Magnetic Amplifier Experiments
Safety Fuse Protected
Load Type Lamp Load Included
Indicating Lamps Fitted for Operation Confirmation
Front Panel Diagrammatic Circuit Layout for Easy Learning
Environment Suitable for Laboratory and Training Institutes

Magnetic Amplifier Trainer Series & Parallel Trade Information

Supply Ability 5 Unit Per Week
Delivery Time 4-5 Days

Product Description

DESCRIPTION

Amplification is the control of a larger output quantity by the variation of a smaller input quantity. Such amplification can be performed by saturable reactors connected either in series or in parallel. This set up consists two such reactors, AC and DC power supply, two meters for load and control currents and a fixed value RL. The set up to study the characteristics of series - parallel connected magnetic amplifier, has two identical gate and control windings wound upon split deltamax cores, which are placed together to form two saturable reactors. A compensation winding is wound between the gate windings and connected with control windings for proper phase correction. Sockets are given to connect the amplifier gate windings in series parallel mode, while control windings are joined together with compensation windings internally. A control bias battery in form of regulated DC 0-3Volt supply with a DC mAmeter to read IC, and current limit resistance is provided to study control and saturation characteristics.The polarity of DC current applied to control winding may be changed with polarity selector. Two fixed value (20 and 100 OHM) RL are given to study the effect upon transfer characteristics, with stepped down fixed AC supply with an AC ammeter to read load current IL.

TECHNICAL SPECIFICATIONS

To study input-output characteristic of a magnetic amplifier

Two saturable reactors in one frame.
Two Rectifiers.
Fixed Resistive load.
DC bias voltage.
One potentiometer.
Two digital meters.
IC regulated power supply for complete circuitry.
220V ±10%, 50Hz mains operated.
User's Manual with patch cords

Comprehensive Learning Experience

The Magnetic Amplifier Trainer Series & Parallel provides a hands-on learning platform for mastering magnetic amplifier principles. Students and trainees can engage with both series and parallel module experiments using the included accessories. The trainer is designed for rapid practical understanding, facilitated by a detailed front-panel circuit diagram and intuitive controls.

Built-in Operational Safety

Operator safety is prioritized through the use of fuse protection and a mild steel, powder-coated enclosure, making the device robust for laboratory use. Fitted indicating lamps and an analog meter help users verify connections and experiment progress safely and accurately.

Designed for Maximum Utility

Its compact and modular design, combined with user-friendly features like banana socket terminals, potentiometer controls, and high-precision measurements, make it an indispensable tool for educational environments. The inclusion of a lamp load and guiding instruction manual ensures comprehensive, hassle-free experimentation.

FAQs of Magnetic Amplifier Trainer Series & Parallel:

Q: How do I set up the Magnetic Amplifier Trainer for experiments?

A: To set up the Magnetic Amplifier Trainer, connect the provided wires to the banana socket terminals as shown in the front panels circuit diagram. Ensure the trainer is connected to a 230V AC, 50Hz power source before commencing any experiments.

Q: What safety features are integrated into the trainer?

A: This trainer includes a fuse for overcurrent protection, a powder-coated steel body for increased durability, and fitted indicating lamps to confirm the correct operation. These features are provided to promote safe laboratory usage.

Q: When should the analog meter and indicating lamps be observed during experiments?

A: Monitor the analog meter and indicating lamps throughout the experiment to verify proper circuit operation and load status. These indicators assist in tracking input adjustments and confirm active circuit connections.

Q: Where is this trainer best utilized?

A: The Magnetic Amplifier Trainer is ideal for laboratory settings and training institutes. Its design suits educational and testing environments, offering both robust performance and compact portability.

Q: What process is followed to adjust experiment parameters?

A: Input parameters can be easily adjusted using the built-in potentiometers. Refer to the instruction manual for specific settings required for each experiment module, ensuring precision and repeatability.

Q: Who benefits from using this trainer?

A: Students, educators, and professionals engaged in electrical training or testing benefit significantly from this trainer, as it offers practical experience and high measurement accuracy in magnetic amplifier experiments.
