Analog / linear IC Tester

Analog / linear IC Tester

Get a Price/Quote

Product Details:

  • Humidity Up to 85% RH
  • Temperature 0C to 50C (Operating)
  • Mounting Type Bench-top
  • Power Supply 230V AC, 50Hz
  • Test Range Linear/Analog ICs (LM324, 741, LM358, etc.)
  • Accuracy Functional testing, pass/fail indication
  • Automation Grade Manual
  • Click to view more
Request To Call Back Send Inquiry
X

Analog / linear IC Tester Price And Quantity

  • 1 Unit
  • Checks Op-Amps, timers, voltage regulators, comparators, etc.
  • LED Pass/Fail Status
  • 240mm x 175mm x 60mm (Approx.)
  • Analog / Linear IC Tester
  • Overload and short circuit protection
  • Instruction manual, power cord
  • Available
  • ZIF (Zero Insertion Force) Socket for 8-40 pin DIP ICs

Analog / linear IC Tester Product Specifications

  • DIP ICs, 8-40 pin
  • 230V AC
  • Functional testing, pass/fail indication
  • Testing of analog/linear ICs in laboratory and servicing
  • Compact design, easy operation, supports multiple IC types
  • 50Hz
  • Instantaneous
  • Depends on IC type
  • Up to 85% RH
  • Manual
  • Push button/Manual selection
  • 2.5 Kg (Approx.)
  • Bench-top
  • Standard 0.3 to 0.6 IC packages
  • Manual, depends on IC change
  • Educational laboratory, servicing/testing
  • 0C to 50C (Operating)
  • One IC per test
  • LED Indicators
  • Linear/Analog ICs (LM324, 741, LM358, etc.)
  • ICs compatible per datasheet
  • 230V AC, 50Hz
  • Checks Op-Amps, timers, voltage regulators, comparators, etc.
  • LED Pass/Fail Status
  • 240mm x 175mm x 60mm (Approx.)
  • Analog / Linear IC Tester
  • Overload and short circuit protection
  • Instruction manual, power cord
  • Available
  • ZIF (Zero Insertion Force) Socket for 8-40 pin DIP ICs

Analog / linear IC Tester Trade Information

  • 5 Unit Per Week
  • 4-5 Days
  • Australia, South America, Western Europe, Middle East, Central America, Asia, Eastern Europe, North America, Africa
  • All India

Product Description

Analog IC Tester

FEATURES

  • It has 12/16 keys for its operation.
  • Battery & Mains operation
  • Potential free 40 pin universal ZIF socket.
  • Digital Display to show IC number, PASS & FAIL Status, Operations display.
  • Tests most of the ICs in DIP package. The list includes Operational amplifiers, voltage comparators, transistor arrays, optocouplers, analog switches, voltage followers, timers, A to D converters, D to A converters and miscellaneous analog ICs.
  • Handheld size
  • Audio alarm to user whenever it is required.
TEST LIBRARY

Opto Couplers
MCT2 MCT2E 4N25 4N26 4N27 4N28 4N32 4N33 4N35 4N36 4N37 6N135 6N136 6N137 6N138 6N139 TIL111 TIL112 TIL113

Transistor Arrays
ULN2001 ULN2002 ULN2003 ULN2004 ULN2005 ULN2064 ULN2065 ULN2066 ULN2067 ULN2068 ULN2069 ULN2074 ULN2075 TD62501 TD62502 TD62503 TD62504 TD62505 TD62506 TD62507 75064 75065 75066 75067 75068 75069 75074 75075 75430 75446 75447 75448 75449 75450 75460 75465 75466 75467 75468 75469 75470 75491 75492

Comparators
LM111(8/14 pin) LF111 LM119 LM139LM160(8/14 pin) LM161 LM193 LM211(8/14pin) LF211 LM219 LM239 LM260(8/14 pin) LM261 LM293 LM311(8/14pin) LF311 LM319 LM339 LM360 (8/ 14pin) LM361 LM393 LH2111 LH2211 LH2311 LM2901 LM3302 HA17339 HA17393 HA17901 HA17903

Operational Amplifiers
LM101 LM107 LM108 LM112 LM124 LM143 LM144 LM148 LM149 LM158 LM192 LM201 LM207 LM208 LM212 LM216 LM224 LM228 LM249 LM258 LM292 LM301 LM307 LM308 LM312 LM316 LM324 LM343 LM344 LM348 LM349 LM351 LF356 LF357 LM358 LM392 LM709 LM714 LM725 LM741 (8/ 14 pin) LM747 (10/14 pin) LM748 LM1458 LM1558 LM2902 LM2924 LM3301 LM3401 HA17080 HA17082 HA17083 HA17084 HA17301 HA17324 HA17358 HA17458 HA17474 HA17558 HA17741(8/14 pin) HA17747 HA17902 HA17904 UCOP01 UCOP02 OP07 OP27 CA3130 CA3140 TL074 TL084


Versatile IC Compatibility

This Analog/Linear IC Tester accommodates a broad spectrum of standard 8 to 40 pin DIP ICs, including popular models like LM324, 741, and LM358. Thanks to its ZIF (Zero Insertion Force) socket, technicians can easily test various analog and linear ICs without risking damage or misalignment. Whether youre engaged in laboratory research or electronic servicing, this tester ensures precise and efficient examination.


Reliable Pass/Fail Indication

The LED status indicators provide immediate pass/fail feedback for each tested IC. This eliminates guesswork and streamlines troubleshooting. The device delivers functional accuracy and relies on straightforward visual cues, allowing users of any skill level to interpret results swiftly during manual testing.


Robust Protection and Safety

Built-in safety mechanisms such as fuse protection and safeguards against overload and short circuits enhance user safety and instrument longevity. These features, combined with a sturdy, compact structure, allow for worry-free operation, even in demanding environments or when frequently switching test ICs.

FAQs of Analog / linear IC Tester:


Q: How does the ZIF socket simplify IC testing on this device?

A: The ZIF (Zero Insertion Force) socket allows users to insert and remove ICs without applying excessive pressure, reducing the risk of bent pins or socket damage. This makes the tester ideal for repeated and quick IC replacement during evaluations.

Q: What types of ICs can be tested with this Analog/Linear IC Tester?

A: This instrument covers linear and analog ICs such as operational amplifiers (e.g., LM324, 741), voltage regulators, timers, and comparators. It supports 840 pin DIP packages and checks functional integrity with LED pass/fail indicators.

Q: When should I use this tester in my workflow?

A: Use this IC tester whenever you need to verify the functional status of analog or linear ICs, especially during quality control, restoration, or troubleshooting in laboratories, service centers, or educational environments.

Q: What safety features does the tester offer during operation?

A: The device incorporates fuse protection and additional safeguards against overload and short circuits, ensuring safe and reliable operation during every manual test cycle.

Q: How do I operate the Analog/Linear IC Tester?

A: Operation is straightforward: insert your IC into the ZIF socket, select the appropriate mode with the push button, and observe the instant LED indication for a pass or fail status. The included instruction manual guides users through detailed procedures.

Q: What are the main benefits of using this IC tester?

A: Key benefits include fast and accurate pass/fail detection, protection for both the user and device, wide IC compatibility, and ease of usemaking it suitable for various educational, laboratory, and servicing purposes.

Q: Where is this tester most commonly used?

A: This Analog/Linear IC Tester is widely employed in electronics laboratories, education facilities, servicing and repair workshops, and research centers across India and worldwide.
