Digital Flux Meter / Gauss Meter

Get a Price/Quote

Product Details:

Accuracy 1% of reading
Response Time Fast response (1 Sec)
Specimen Size Custom as per probe
Temperature 0C to 50C
Test Range 0 to 19999 Gauss/0 to 19999 Maxwell
Power Supply 230V AC, 50Hz
Resolution 1 Gauss/1 Maxwell
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Digital Flux Meter / Gauss Meter Price And Quantity

Minimum Order Quantity 1 Unit

Dimensions 170 mm x 85 mm x 38 mm
Battery Back-up Optional
Storage Temperature -10°C to 60°C
Body Material ABS Plastic
Compliance CE Certified
Probe Type Hall Effect
Sample Rate 2 samples/sec
Calibration Factory calibrated with certificate

Digital Flux Meter / Gauss Meter Product Specifications

Features Auto zero, polarity indication, hold feature
Equipment Type Digital Flux Meter / Gauss Meter
Number of Specimens Single Specimen
Application Measurement of magnetic field strength and flux
Measuring Range 0 to 20,000 Gauss
Display Type Large Digital LCD
Frequency 50 Hz
Operating Voltage 230V AC
Usage Laboratory, R&D, industrial
Test Speed Manual/Variable
Humidity 0-80% RH non-condensing
Test Range 0 to 19999 Gauss/0 to 19999 Maxwell
Temperature 0C to 50C
Response Time Fast response (1 Sec)
Specimen Size Custom as per probe
Accuracy 1% of reading
Machine Weight Approx. 1.2 Kg
Interface Type BNC Probe Connector, Banana jack output
Mounting Type Portable/Handheld
Automation Grade Manual/Automatic modes
Control Mode Digital Control
Resolution 1 Gauss/1 Maxwell
Power Supply 230V AC, 50Hz

Dimensions 170 mm x 85 mm x 38 mm
Battery Back-up Optional
Storage Temperature -10°C to 60°C
Body Material ABS Plastic
Compliance CE Certified
Probe Type Hall Effect
Sample Rate 2 samples/sec
Calibration Factory calibrated with certificate

Digital Flux Meter / Gauss Meter Trade Information

Supply Ability 5 Unit Per Week
Delivery Time 4-5 Days
Main Export Market(s) Australia, South America, Eastern Europe, Western Europe, Central America, Asia, North America, Africa
Main Domestic Market All India

Product Description

The Gauss meter operates on the principle of Hall Effect in Semiconductors.

The small Hall voltage is amplified through a high stability amplifier that a millivoltmeter connected at the output of the amplifier can be calibrated directly in magnetic Field unit.

Technical Specifications :

Range : 0-2K gauss and 0-20 Kg
Resolution : One Gauss at 0-2 K gauss range
Accuracy :0.5%
Display : 3 1/2 digit 7 seg. (DPM)
Detector : Hall probe with an imported hall element
Power : 220V, 50 Hz
Special : Indicate the direction of the magnetic field.

Precision Magnetic Measurement

This digital flux meter offers a wide measurement range of 0 to 19999 Gauss/Maxwell and ensures highly accurate and fast response readings, making it indispensable for scientific and industrial applications. The factory calibration with certificate provides users confidence in measurement reliability and repeatability, while the Hall Effect probe delivers direct, contactless sensing of the magnetic field.

User-Friendly Design and Versatility

Built with ABS plastic for durability and lightweight handling, this handheld device is both portable and robust. The large digital LCD and intuitive controlsincluding manual and automatic test speed optionsenable seamless operation. Compatibility with various specimen sizes thanks to the customizable probe adds to its flexibility, supporting a wide range of magnetic measurements.

Reliable and Safe Operation

CE compliance ensures high safety standards, while the wide operating conditions (humidity up to 80% RH, temperature 0C to 50C) make it adaptable to various environments. Optional battery backup assures uninterrupted usage, and features like auto zero and polarity indication support error-free measurement sessions.

FAQs of Digital Flux Meter / Gauss Meter:

Q: How does the Hall Effect probe in this flux meter work?

A: The Hall Effect probe detects magnetic fields by generating a voltage proportional to the field strength when exposed to a magnetic source. This enables direct, accurate measurement of magnetic flux and field strength, even in dynamic environments.

Q: What is the process for calibrating the Digital Flux Meter, and is a calibration certificate included?

A: Each unit undergoes factory calibration before dispatch, ensuring measurement accuracy and traceability. A calibration certificate is provided with the equipment, detailing the standards and procedures used.

Q: Where can this Digital Flux Meter be used effectively?

A: It is suitable for laboratory work, R&D, and industrial applications where reliable magnetic measurement is essential. Its rugged, portable design and wide environmental tolerances make it ideal for both field and indoor usage.

Q: What are the main benefits of using this flux meter in industrial or laboratory settings?

A: Key benefits include high measurement accuracy (1%), broad measuring range, fast response, digital control, and features like auto zero, polarity indication, and data hold. These attributes promote efficient, error-free, and repeatable magnetic field and flux evaluation.

Q: How is the measuring range and resolution suitable for specialized applications?

A: With a range from 0 to 20,000 Gauss and a resolution of 1 Gauss/1 Maxwell, the meter supports high-precision magnetic analysis. This makes it suitable for both fine-scale and high-field applications across automation, manufacturing, and research disciplines.

Q: What is the recommended power supply and backup option for uninterrupted operation?

A: The meter operates on a standard 230V AC, 50Hz power supply. For enhanced mobility or power failure situations, an optional battery backup ensures continuous use.

Q: How does the device accommodate various specimen sizes and testing needs?

A: The instruments compatible probes can be customized for different specimen sizes, and manual or automatic control modes allow flexible adaptation to diverse testing protocols.
