Measurement of Temperature using RTD

Get a Price/Quote

Product Details:

Power AC Powered
Display Digital (LED) Display
Voltage 220 V AC, 50 Hz
Usage Laboratory/Instrumentation for temperature measurement
Product Type Temperature Measurement Trainer Kit
Material Mild Steel Enclosure, ABS Front Panel
Design Bench-top, Compact Modular
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Measurement of Temperature using RTD Price And Quantity

Minimum Order Quantity 1 , , Unit

Application Educational Demonstration, Industrial Training
Calibration Factory Calibrated
Output Type 4-20 mA Current Output / Digital Output
Environment Indoor/Lab Use Only
Temperature Range 0°C to 150°C
Resolution 0.1°C
Accessories Included RTD Sensor, Connecting Wires, Power Cord, User Manual
Cable Length 1.5 meters (sensor cable)
Protection Overload and Short Circuit Protected
Operating Temperature 0°C to 50°C
Sensor Type RTD PT100, 3-wire
Indicator Power ON and Fault Indicators
Measurement Principle Change in Electrical Resistance with Temperature
Mounting Desktop/Bench-top

Measurement of Temperature using RTD Product Specifications

Design Bench-top, Compact Modular
Charging Time Not Applicable (Mains Powered)
Weight Approximately 2.5 kg
Dimension (L*W*H) 250 mm x 200 mm x 100 mm
Power Source Electric Mains
Voltage 220 V AC, 50 Hz
Usage Laboratory/Instrumentation for temperature measurement
Material Mild Steel Enclosure, ABS Front Panel
Detector Platinum Resistance Temperature Detector (RTD, PT100)
Product Type Temperature Measurement Trainer Kit
Accuracy 0.5C
Power AC Powered
Display Digital (LED) Display

Application Educational Demonstration, Industrial Training
Calibration Factory Calibrated
Output Type 4-20 mA Current Output / Digital Output
Environment Indoor/Lab Use Only
Temperature Range 0°C to 150°C
Resolution 0.1°C
Accessories Included RTD Sensor, Connecting Wires, Power Cord, User Manual
Cable Length 1.5 meters (sensor cable)
Protection Overload and Short Circuit Protected
Operating Temperature 0°C to 50°C
Sensor Type RTD PT100, 3-wire
Indicator Power ON and Fault Indicators
Measurement Principle Change in Electrical Resistance with Temperature
Mounting Desktop/Bench-top

Measurement of Temperature using RTD Trade Information

Supply Ability 5 , , Unit Per Week
Delivery Time Days
Main Domestic Market All India

Product Description

RTD Trainer (PT 100)

SPECIFICATION

Study of RTD as temperature measuring transducer
Mercury thermometer and heater 10W (optional)
RTD(PT-100) probe with protect cover
Bridge circuit for transducer
Differential amplifier with feedback
Lead compensation system
Sockets provided to study the process to find out the error rate
3.5 digit DPM as temperature indicator
Interconnection: 2/4mm banana sockets
220V 50HZ mains operated
Enclosed in an attractive ABS plastic cabinet with cover
Accessories: Users Manual with patch cords

Accurate Temperature Measurement

Leveraging a platinum resistance temperature detector (RTD, PT100), this device delivers reliable readings from 0C to 150C. Factory calibration ensures consistently precise measurements, essential for laboratory and educational purposes. Its 3-wire configuration minimizes lead resistance errors, enhancing accuracy for demonstration and training exercises.

User-Friendly Design and Display

The bench-top system features a digital LED display, allowing users to easily observe temperature readings. Fault and power indicators promote safe operation. Its modular, compact design makes it ideal for desktop or laboratory bench use, while accessories such as connecting wires and a power cord are provided for immediate setup.

Safety and Durability

Overload and short circuit protection safeguard both users and equipment during operation. The enclosure is built from mild steel with an ABS front panel to withstand intensive lab usage. Each unit is factory calibrated and ready to use upon installation, promoting reliability and reducing setup time.

FAQs of Measurement of Temperature using RTD:

Q: How does the RTD PT100 measure temperature in this apparatus?

A: The RTD PT100 functions by detecting changes in electrical resistance as the temperature varies. As the temperature increases or decreases, the electrical resistance of the platinum element (PT100) changes, and this variance is precisely measured and displayed digitally.

Q: What makes this temperature measurement apparatus suitable for educational and industrial training purposes?

A: The apparatus offers robust accuracy (0.5C), a wide temperature range (0C to 150C), and user-friendly features like a digital LED display and power/fault indicators. Its bench-top, modular design and included accessories make it ideal for hands-on laboratory training and educational demonstrations.

Q: When should the factory calibration be re-checked or re-calibrated?

A: While the unit is factory calibrated for immediate use, periodic checks or recalibration may be advisable after extended use or if consistent measurement discrepancies are observed during applications. Refer to the user manual for calibration instructions and recommendations.

Q: Where is this temperature measurement apparatus best utilized?

A: Designed specifically for indoor and laboratory settings, this apparatus is perfect for educational institutions, training centers, and research labs where accurate indoor temperature measurements are essential.

Q: What outputs are available, and how can they be used in a laboratory setup?

A: The instrument provides either a 4-20 mA current output or a digital output, enabling easy integration with recorders, PLCs, or computer interfaces for data logging and analysis in laboratory or classroom scenarios.

Q: What is the process for setting up and using the system?

A: Simply place the bench-top unit on a stable surface, connect the RTD sensor using the provided wires, plug in the power cord to a 220 V AC outlet, and switch on the device. The LED display will show current temperature readings. Follow safety instructions and refer to the user manual for further guidance.

Q: What are the benefits of using this RTD-based temperature measurement apparatus in a learning environment?

A: Students and trainees benefit from hands-on experience with reliable, industry-standard technology. The system provides real-time, precise measurements, enhances understanding of temperature sensing principles, and cultivates skills crucial for instrumentation and process control roles.
