Study of Dielectric Constant and Curie Temperature of Ferroelectric Ceramics

Product Description

Product Description

Description of theExperimental Setup

1 ProbesArrangement

It has twoindividually spring loaded probes. The probes arrangement is mounted in asuitable stand, which also holds the sample plate. To ensure the correctmeasurement of sample temperature, the RTD is embedded in the sample plate justbelow the sample. This stand also serves as the lid of temperature controlledoven. Proper leads are provided for connection to Capacitance Meter andTemperature Controller.

2 Sample Barium Titanate (BaTiO 3)

3 Oven This is a high quality temperature controlled oven. The oven has been designed for fast heating and cooling rates which enhances the effectiveness of the controller.

4 Main UnitsThe Set-up consists of two unitshoused in the same cabinet.

Oven Controller PlatinumRTD (A class) has been used for sensing the temperature.

Specifications

Temperature Range  Ambient to 200 degrees C

Digital CapacitanceMeter This a compact directreading Instrument for the measurement of capacitance of the sample.

Specifications

Range 50-6000 pf
