8085 Microprocessor Training Kit With Inbuilt Power Supply

8085 Microprocessor Training Kit With Inbuilt Power Supply

Get a Price/Quote

Product Details:

  • Power Inbuilt Power Supply, 230V AC/50Hz operation
  • Usage Educational, Laboratory, Training
  • Voltage +5V, +12V, -12V DC output for system and peripherals
  • Display 6-Digit Seven Segment LED Display
  • Product Type 8085 Microprocessor Training Kit
  • Material ABS Plastic Body with Metal Base
  • Design Table-top, user-friendly layout
  • Click to view more
Request To Call Back Send Inquiry
X

8085 Microprocessor Training Kit With Inbuilt Power Supply Price And Quantity

  • 1 Unit
  • 32-key hexadecimal keypad
  • Provided with 50-pin FRC connector for expansion
  • Hexadecimal machine code
  • Fuse and over-voltage protection circuit
  • Monitor, Step-by-step, and Run
  • Power cord, user manual, patch cords
  • 8085A with 3 MHz clock frequency
  • 8255 Programmable Peripheral Interface onboard
  • 32KB (16KB EPROM, 16KB RAM)
  • Available for logic probes, interrupt and serial interfacing

8085 Microprocessor Training Kit With Inbuilt Power Supply Product Specifications

  • 2.5 Kg (approx.)
  • 8085 Microprocessor Training Kit
  • ABS Plastic Body with Metal Base
  • Inbuilt mains-powered supply
  • LED indicators for status
  • +5V, +12V, -12V DC output for system and peripherals
  • 6-Digit Seven Segment LED Display
  • Not applicable (mains powered)
  • High operational accuracy for educational use
  • Educational, Laboratory, Training
  • 350 mm x 225 mm x 100 mm (approx.)
  • Table-top, user-friendly layout
  • Inbuilt Power Supply, 230V AC/50Hz operation
  • 32-key hexadecimal keypad
  • Provided with 50-pin FRC connector for expansion
  • Hexadecimal machine code
  • Fuse and over-voltage protection circuit
  • Monitor, Step-by-step, and Run
  • Power cord, user manual, patch cords
  • 8085A with 3 MHz clock frequency
  • 8255 Programmable Peripheral Interface onboard
  • 32KB (16KB EPROM, 16KB RAM)
  • Available for logic probes, interrupt and serial interfacing

8085 Microprocessor Training Kit With Inbuilt Power Supply Trade Information

  • 5 Unit Per Week
  • 4-5 Days
  • Australia, South America, Eastern Europe, Western Europe, Middle East, Africa, Central America, Asia, North America
  • All India

Product Description

8085 MICROPROCESSOR TRAINER KIT WITH LED DISPLAY

SPECIFICATIONS

  • Based on 8085 CPU operating at 6.144 MHz crystal
  • 8K bytes of EPROM loaded with powerful monitor program
  • 8K bytes of RAM available to the user
  • Total on board memory expansion upto 64K bytes using 2732/2764/27128/6264/ 62256
  • with 1 socket of 28 pin
  • Battery back up for RAM with 3.6V rechargeable cell
  • Memory mapping definable by the user
  • 16 bit programmable TIMER/COUNTER using 8253
  • Additional serial port using 8251 (OPTIONAL)
  • Real Time Clock (OPTIONAL)
  • 48 I/O lines provided through 8255
  • RS-232C interface through SID/SOD Lines with Auto baud rate
  • Two modes of commands: Hex Key pad & Serial mode
  • All address, data & control lines are buffered and made available at the edge connector as per STD bus configuration
  • 25/28 key hexadecimal keyboard and six seven segment displays through 8279
  • Powerful software commands like Relocate, String, Fill, Insert, Delete, Block Move, Examine/Compare Memory, Examine Register, Insert Data, Delete Data, Single Step, GO, Break Point in both Serial & Keyboard mode
  • Facility for Downloading/Uploading files from/to PC
  • Enclosed in an attractive ABS plastic cabinet with cover
  • In-built Power supply
  • User Manual




Integrated Power and Protection

The inbuilt power supply delivers stable +5V, +12V, and -12V DC outputs, supporting both system and peripheral devices. The kit is safeguarded by fuse and over-voltage protection, ensuring long-term reliability and secure operation during extensive educational use.


Versatile Programming and Connectivity

Offering Monitor, Step-by-step, and Run programming modes, the kit supports hexadecimal machine code input through a 32-key keypad. It features onboard 8255 Programmable Peripheral Interface and multiple connectors for logic probes, interrupts, and serial communications, making it highly adaptable for expansion and experimentation.


Educational Excellence and Design

Specifically crafted for academic and laboratory settings, the kit boasts a user-centered, table-top layout with LED indicators to display system status. Accessories such as a power cord, user manual, and patch cords are included, making it easy to install and immediately operational for trainees.

FAQs of 8085 Microprocessor Training Kit With Inbuilt Power Supply:


Q: How is the 8085 Microprocessor Training Kit powered and what protection does it offer?

A: The kit is mains-powered, operating at 230V AC/50Hz with an inbuilt supply that provides +5V, +12V, and -12V DC. It incorporates a fuse and an over-voltage protection circuit to safeguard internal components and ensure safe, continuous operation.

Q: What programming modes are available and how are they used?

A: The training kit offers Monitor, Step-by-step, and Run programming modes. Users can enter instructions using the 32-key hexadecimal keypad, test and debug programs incrementally, or execute them in full via the selected mode to facilitate learning and experimentation.

Q: Where can this 8085 kit be utilized?

A: This product is suitable for use in educational institutions, laboratories, and training workshops, providing hands-on experience with microprocessor architecture and interfacing for students and trainees.

Q: What interfaces and expansion capabilities does the kit support?

A: Expansion is straightforward with a 50-pin FRC connector, and the onboard 8255 Programmable Peripheral Interface allows extended input/output operations. Additional connectors accommodate logic probes as well as interrupt and serial interfaces for varied experimental setups.

Q: What accessories are included with the 8085 Microprocessor Training Kit?

A: Each unit comes equipped with a power cord, user manual, and patch cords. These accessories, along with the user-friendly design, ensure that users can quickly set up and begin practical sessions.

Q: What is the primary benefit of using this kit in educational settings?

A: The kit provides a comprehensive, high-accuracy platform for learning microprocessor programming and hardware interfacing. Its robust features, protected operation, and user-oriented design support practical teaching and hands-on skill development.
