Torque Measurement Trainer

Get a Price/Quote

Product Details:

Voltage 230V AC, 50Hz
Display Digital LCD Display
Usage Educational, Laboratory, Industrial Training
Power 30W
Product Type Trainer Kit
Material Mild Steel, Aluminum, Acrylic
Design Bench-top Modular Design
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Torque Measurement Trainer Price And Quantity

Minimum Order Quantity 1 , , Unit

Overload Protection Electronic Limit Circuit
Calibration Factory Calibrated & Traceable
Speed Range 0 1500 rpm
Connectivity USB and BNC Ports
Sensor Output Standard 05V DC
Torque Display Resolution 0.01 Nm
Read-out High-resolution digital meter
Mounting Anti-vibration rubber feet
Training Manual Included
Measuring Range 0 20 Nm
Operating Temperature 10C to 45C

Torque Measurement Trainer Product Specifications

Product Type Trainer Kit
Usage Educational, Laboratory, Industrial Training
Display Digital LCD Display
Weight Approx. 15 Kg
Accuracy 1% of Full Scale
Material Mild Steel, Aluminum, Acrylic
Detector Rotary type torque transducer
Voltage 230V AC, 50Hz
Dimension (L*W*H) Approx. 400 mm x 500 mm x 450 mm
Design Bench-top Modular Design
Power Source Electric
Charging Time Not Applicable (Mains Powered)
Power 30W

Overload Protection Electronic Limit Circuit
Calibration Factory Calibrated & Traceable
Speed Range 0 1500 rpm
Connectivity USB and BNC Ports
Sensor Output Standard 05V DC
Torque Display Resolution 0.01 Nm
Read-out High-resolution digital meter
Mounting Anti-vibration rubber feet
Training Manual Included
Measuring Range 0 20 Nm
Operating Temperature 10C to 45C

Torque Measurement Trainer Trade Information

Supply Ability 5 , , Unit Per Week
Delivery Time 4-5 Days

Product Description

TORQUE MEASUREMENT KIT

Range: 0 to 1 Kg-m

Resolution: 0.1 kg/m.

Excitation: 5 Volts DC

TECHNICAL SPECIFICATIONS

Range:0 to 1 Kg-m

Resolution:0.1 kg/m.

Excitation:5 Volts DC

Analog Output: 2 Volts, FSD

With 4 Nos. Weight of 250 gm

3.5 digits DPM as displacement indicator

Interconnection:2/4 mm banana sockets

DC Supply: Built in IC regulated power supplies

220V 10%, 50 Hz mains operated

Enclosed in an attractive ABS plastic cabinet with cover

Accessories: User Manual with patch cords

Precision and Reliability

Engineered for high-accuracy torque measurement, this trainer incorporates a rotary type torque transducer and delivers precise results with a digital LCD read-out at 0.01 Nm resolution. Factory calibration ensures traceability, while 1% accuracy of full scale instills confidence in every reading.

Comprehensive Training Features

Designed for education and industrial application, the trainer includes a detailed manual, overload protection, and user-friendly controls. Its modular bench-top structure, anti-vibration feet, and robust materials guarantee stability and durability in laboratory or classroom settings.

Ease of Integration and Operation

With intuitive high-resolution digital meters, USB and BNC ports, and mains-powered operation, the system integrates seamlessly into modern labs. Covering a broad range of torque and speed, its suited for hands-on learning and advanced research alike. Its lightweight construction supports portability and convenience.

FAQs of Torque Measurement Trainer:

Q: How does the Torque Measurement Trainer ensure precise measurement?

A: This trainer utilizes a rotary type torque transducer with factory calibration that is traceable, guaranteeing 1% accuracy of full scale. The high-resolution digital LCD display allows torque readings with a resolution of 0.01 Nm, ensuring measurement precision for various applications.

Q: What applications are most suitable for this torque trainer?

A: It is ideal for educational, laboratory, and industrial training environments. The reliable build and versatile measurement range make it perfect for academic demonstrations, experimental investigations, and technician training sessions in technical institutes or R&D labs.

Q: Where can I access the measurement data from this trainer?

A: Measurement data can be accessed directly from the high-resolution digital LCD meter. For data logging or advanced analysis, the trainer offers connectivity through standard USB and BNC ports to integrate with laboratory computers or external equipment.

Q: What is the process for setting up the Torque Measurement Trainer?

A: Simply position the bench-top unit on a stable surface using its anti-vibration rubber feet. Connect to mains power (230V AC, 50Hz) and utilize the easily accessible front-panel controls. The included training manual provides step-by-step setup and operation instructions.

Q: What safety features protect the trainer against overload?

A: The system is equipped with an electronic limit circuit that offers overload protection, preventing damage to the sensor and ensuring operator safety during high torque experiments.

Q: When is calibration or maintenance required for this device?

A: The trainer comes factory calibrated and traceable, requiring minimal maintenance under normal use. Routine visual inspections are advisable to ensure long-term reliability, but recalibration is typically only needed if the unit is subjected to physical impact or extreme conditions.

Q: What are the main benefits of using this torque measurement trainer?

A: The trainer provides accurate, traceable torque measurements, supports data integration via USB/BNC, and is built to be durable yet portable. Its user-friendly interface and comprehensive manual make it an excellent tool for hands-on mechanical measurement learning and technical skills development.
