Two Stage RC Coupled Transistor amplifier

Get a Price/Quote

Product Details:

Low Impedance Can drive loads up to 1 k
Voltage 9V DC (operating voltage)
Harmonic Distortion < 2% (at rated output)
Material Premium quality glass epoxy PCB, tin-plated copper traces
Frequency (MHz) 0.02 to 0.02 MHz (20 Hz to 20 kHz)
Channels Mono (Single Channel)
Power 9V DC, 500 mW max
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Two Stage RC Coupled Transistor amplifier Price And Quantity

Minimum Order Quantity 1 Unit

Phase Shift 180 per stage (total 360)
Idle Current Approx. 3 mA
PCB Mounting Drilled holes for fixed mounting
Operating Temperature 0 C to 50 C
Output Load Impedance 1 k 10 k recommended
Application Electronic lab experiments, audio preamp demonstration, educational training kit
Coupling Capacitor Values Input/Inter-stage: 1 F, Output: 10 F
Transistor Used BC547 or equivalent NPN (per stage)
Gain (Mid Frequency) > 100 (overall, typical)
Terminals Soldered pin terminals for input, output, and power connection
Amplification Stages 2 (Two-stage RC coupled)
Resistor Value Range 470 to 220 k (varies per circuit section)

Two Stage RC Coupled Transistor amplifier Product Specifications

Dimension (L*W*H) 150 mm x 100 mm x 40 mm
Color Green PCB, Black Components
Harmonic Distortion < 2% (at rated output)
Frequency (MHz) 0.02 to 0.02 MHz (20 Hz to 20 kHz)
S/N Ratio > 60 dB
Voltage 9V DC (operating voltage)
Weight (kg) 0.19 kg
Low Impedance Can drive loads up to 1 k
Power 9V DC, 500 mW max
Noise Level 1 mV (at output, no input signal)
Material Premium quality glass epoxy PCB, tin-plated copper traces
Channels Mono (Single Channel)
Input Signal 10 mV to 60 mV (peak-to-peak, audio)

Phase Shift 180 per stage (total 360)
Idle Current Approx. 3 mA
PCB Mounting Drilled holes for fixed mounting
Operating Temperature 0 C to 50 C
Output Load Impedance 1 k 10 k recommended
Application Electronic lab experiments, audio preamp demonstration, educational training kit
Coupling Capacitor Values Input/Inter-stage: 1 F, Output: 10 F
Transistor Used BC547 or equivalent NPN (per stage)
Gain (Mid Frequency) > 100 (overall, typical)
Terminals Soldered pin terminals for input, output, and power connection
Amplification Stages 2 (Two-stage RC coupled)
Resistor Value Range 470 to 220 k (varies per circuit section)

Two Stage RC Coupled Transistor amplifier Trade Information

Supply Ability 5 Unit Per Week
Delivery Time 4-5 Days
Main Export Market(s) Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Central America, Asia, Africa
Main Domestic Market All India

Product Description

Two stage RC Coupled Transistor Amplifier (Frequency Response)

Objective : To study Frequency Response of Single stage two stage RC coupled Common Emitter Transistor Amplifier.

Features : Instrument comprises of DC Regulated Power Supply, Circuit diagram is printed, components mounted on the front panel.

Robust Two-Stage RC Coupled Design

This amplifier utilizes a classic two-stage RC coupled architecture, allowing effective signal amplification across the 20 Hz to 20 kHz frequency spectrum. Each stage employs a BC547 or similar NPN transistor, with carefully chosen coupling capacitors for optimal frequency response.

User-Friendly and Educational

Engineered for electronics laboratories and training settings, the amplifier offers easy PCB mounting through drilled holes, as well as clear soldered pin terminals. Its straightforward topology supports hands-on learning and demonstration of signal amplification and phase shift concepts.

Clean Performance for Audio Applications

Delivering over 100x gain at mid frequencies, the unit supports clean audio preamplification with low noise (1 mV at output) and less than 2% harmonic distortion. It can effectively drive loads between 1 k and 10 k, making it suitable for a variety of audio and measurement experiments.

FAQs of Two Stage RC Coupled Transistor amplifier:

Q: How is the Two Stage RC Coupled Transistor Amplifier connected in an experimental setup?

A: The amplifier features soldered pin terminals for input, output, and power connections, facilitating straightforward integration into lab experiments. Simply connect your signal source to the input terminal, the output load to the output terminal, and a 9V DC supply to the power pins.

Q: What types of experiments or demonstrations can this amplifier support?

A: It is ideal for audio preamplification demonstrations, investigation of phase shifts, gain measurement, and other signal amplification studies in electronic training labs. The mono channel and wide frequency response make it suitable for exploring basic audio circuit principles.

Q: When should the recommended load impedance range (1 k 10 k) be observed?

A: For best performance and to maintain signal integrity, ensure that the output load falls between 1 k and 10 k. Loads in this range optimize gain and minimize distortion, especially during audio and measurement experiments.

Q: Where can this amplifier be mounted within a laboratory setup?

A: Designed with drilled holes for fixed PCB mounting, the amplifier can be securely positioned on experiment boards, lab training panels, or inside equipment housings as needed. The compact form factor (150 mm x 100 mm x 40 mm) allows versatile placement.

Q: What is the typical signal input level and what benefit does the amplifier provide in audio applications?

A: Accepting input signals from 10 mV to 60 mV (peak-to-peak), the amplifier boosts weak audio or test signals for easier observation or further processing. Its high signal-to-noise ratio (>60 dB) ensures amplified output with minimal background noise.

Q: How does the phase shift characteristic of this amplifier function?

A: Each RC coupled stage introduces a 180 phase shift, resulting in a total of 360 shift across both stages. This property can be demonstrated and analyzed in classroom or lab environments to illustrate signal inversion and amplification principles.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Amplifiers Characteristics' category

Common Base Amplifier with Function Generator and AC Digital meters Price : 100 INR/Piece Minimum Order Quantity : 1 Input Signal : Function generator (sinusoidal, 1 Hz to 1 MHz) Channels : Single Channel (Common Base configuration) Material : Other, Powder coated MS cabinet Noise Level : <1 mV RMS Power : AC 230V 10%, 50 Hz Low Impedance : Supports load impedance down to 10 Heatsink : Integrated Aluminium Heatsink Weight (kg) : Approx. 2.8 kg Voltage : Signal amplitude up to 15V peaktopeak S/N Ratio : 65 dB Frequency (MHz) : 0.001 to 1 MHz (Range of Function Generator) Dimension (L*W*H) : 340 mm x 220 mm x 90 mm Harmonic Distortion : < 0.5% Color : Grey and Black with printed labels

Send Inquiry

Common Collector Transistor Amplifier Minimum Order Quantity : 1 Input Signal : Audio/Low voltage AC Channels : Single Channel Material : Other, FR4 PCB, Epoxy, Plastic and Metal components Noise Level : Low Power : 0.25 W Low Impedance : Supports load impedance down to 4 Ohms Heatsink : Provided (mounted on transistor) Weight (kg) : 0.025 Voltage : 6V 12V DC S/N Ratio : Greater than 60 dB Frequency (MHz) : 0.02 MHz to 10 MHz (20 Hz 10 MHz) Dimension (L*W*H) : 10 cm x 5 cm x 3 cm Harmonic Distortion : Typically <0.3% Color : Green/Black (As per PCB and component color)

Send Inquiry

Transistor Push Pull Amplifier / Transformer Coupled Amplifier Minimum Order Quantity : 1 Input Signal : Audio, 20 mV to 500 mV Channels : 2 (Stereo) Material : Other, PCB, Metal Chassis, Plastic Knobs Noise Level : Less than 3 dB Power : 1 W to 5 W output Low Impedance : 4 Ohm to 8 Ohm speakers compatible Heatsink : Aluminum, Integrated Weight (kg) : 0.18 Voltage : 12 V DC S/N Ratio : 60 dB Frequency (MHz) : 0.02 to 0.03 (20 Hz to 30 kHz range equivalent) Dimension (L*W*H) : 120 mm x 80 mm x 50 mm Harmonic Distortion : Less than 1.5% Color : Black and Silver

Send Inquiry

Transistor Amplifier Circuits (CE CB CC) Input Signal : Analog Audio/Voltage Channels : Single, Multistage (Based on Configuration) Material : Other, High Quality PCB, Silicon Transistors, Metal Resistor & Capacitor Leads Noise Level : 0.5 mV Power : Battery Operated, 9V DC Low Impedance : Supports loads 8 ohms Heatsink : Included for Output Stage Weight (kg) : 0.08 kg Voltage : 9V DC (Typical, Variable as per circuit type) S/N Ratio : 60 dB Frequency (MHz) : Up to 10 MHz (Depends on Model/Configuration) Dimension (L*W*H) : 9 x 6 x 4 cm Harmonic Distortion : <0.1% (Typical) Color : Multicolor (Assembled Components)
