Operational Amplifier as Differentiator & Integrator

Get a Price/Quote

Product Details:

Display No inbuilt display; results are observed via external oscilloscope
Power Typically 3 mW - 10 mW (depends on op-amp model)
Usage For analog signal processing, waveform shaping, educational and laboratory demonstrations
Voltage 12V to 15V dual supply, or as specified for operational amplifier
Product Type Educational Electronic Trainer / Analog Circuit Module
Material PCB with mounted electronic components
Design Open PCB or boxed module, with clear functional labelling
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Operational Amplifier as Differentiator & Integrator Price And Quantity

Minimum Order Quantity 1 , , Unit

Protection Overvoltage and short-circuit protection on input/output
Component Accessibility Sockets for resistor/capacitor changeover
Operating Environment 0°C to 50°C, non-condensing
Frequency Range DC to 100 kHz (typical), depends on component values
Op-Amp Type General purpose (e.g., 741 or equivalent IC)
Output Terminals 1 (for output observation)
Test Points Provided for signal monitoring
Input Terminals 2 (for signal input and ground)
Input Coupling Capacitive/Resistive depending on mode
Mounting Type Desktop/Laboratory bench
Configuration Switch-selectable Differentiator/Integrator modes

Operational Amplifier as Differentiator & Integrator Product Specifications

Material PCB with mounted electronic components
Product Type Educational Electronic Trainer / Analog Circuit Module
Power Typically 3 mW - 10 mW (depends on op-amp model)
Voltage 12V to 15V dual supply, or as specified for operational amplifier
Usage For analog signal processing, waveform shaping, educational and laboratory demonstrations
Detector Not applicable (not a detection device)
Weight Approx. 350 grams
Display No inbuilt display; results are observed via external oscilloscope
Design Open PCB or boxed module, with clear functional labelling
Power Source External DC dual power supply
Accuracy High accuracy for analog computation and signal waveform transformation
Dimension (L*W*H) Approx. 180 mm x 120 mm x 50 mm (varies with breadboard/enclosure)
Charging Time Not required (operates continuously with power supply)

Protection Overvoltage and short-circuit protection on input/output
Component Accessibility Sockets for resistor/capacitor changeover
Operating Environment 0°C to 50°C, non-condensing
Frequency Range DC to 100 kHz (typical), depends on component values
Op-Amp Type General purpose (e.g., 741 or equivalent IC)
Output Terminals 1 (for output observation)
Test Points Provided for signal monitoring
Input Terminals 2 (for signal input and ground)
Input Coupling Capacitive/Resistive depending on mode
Mounting Type Desktop/Laboratory bench
Configuration Switch-selectable Differentiator/Integrator modes

Operational Amplifier as Differentiator & Integrator Trade Information

Supply Ability 5 , , Unit Per Week
Delivery Time 4-5 Days

Product Description

Operational Amplifier as Differentiators & Integrator (AE 305).

Objective: Operational Amplifier Circuits has been designed to study the Operational amplifier as Differentiator & Integrator.

The instrument comprises of the following built in parts;-

Fixed output DC Regulated power supply of + 12 V.
Operational amplifier IC 741 is placed inside the cabinet and connections are brought out at sockets. Circuit diagram for Differentiator & Integrator are printed on the front panel and components are mounted on the front panel.

Versatile Signal Processing Tool

Switch easily between differentiator and integrator functions to transform or analyze analog signals. The module accommodates input coupling changes (capacitive or resistive), enabling rich hands-on experiments for waveform shaping and analog computation, all in real time.

Customizable Laboratory Module

Sockets for resistors and capacitors offer great flexibility, allowing users to adapt the circuit for various experiments within the DC to 100 kHz frequency range. Clear labeling and readily accessible test points enhance the educational value and usability in laboratory environments.

Precision and Protection Built-In

Designed with reliable overvoltage and short-circuit protection on both input and output, the module delivers high accuracy and long-term resilience. Its open PCB or boxed format ensures easy access to components while maintaining operational safety and ease of use.
