Study of Switching action of a Transistor (BJT)

Get a Price/Quote

Product Details:

Usage Educational, Laboratory, Demonstration of transistor switching action
Power Low (<5W, depends on circuit operation)
Voltage Input: 230V AC, Output: 12V/6V DC (regulated)
Display LED indication, Test points
Product Type Transistor (BJT) Switching Action Trainer
Material Powder-coated metal enclosure, high-quality PCB
Design Tabletop compact trainer designed for easy access of components and test points
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Study of Switching action of a Transistor (BJT) Price And Quantity

Minimum Order Quantity 1 Unit

Study of Switching action of a Transistor (BJT) Product Specifications

Product Type Transistor (BJT) Switching Action Trainer
Display LED indication, Test points
Voltage Input: 230V AC, Output: 12V/6V DC (regulated)
Usage Educational, Laboratory, Demonstration of transistor switching action
Material Powder-coated metal enclosure, high-quality PCB
Weight Approx. 2.5 Kg
Dimension (L*W*H) Approx. 340mm x 210mm x 130mm
Power Source AC mains-powered with inbuilt adapter
Accuracy High - Suitable for educational lab demonstration of switching characteristics
Illuminant LED (for ON/OFF indication)
Design Tabletop compact trainer designed for easy access of components and test points
Power Low (<5W, depends on circuit operation)

Study of Switching action of a Transistor (BJT) Trade Information

Supply Ability 5 Unit Per Week
Delivery Time 4-5 Days
Main Export Market(s) Australia, North America, South America, Eastern Europe, Western Europe, Middle East, Africa, Central America, Asia
Main Domestic Market All India

Product Description

Study of Switching action of a transistor(BJT) (AE 261 )

Objective: Switching circuits using transistors has been designed to study the switching action of a transistor.

Features: Instrument comprises of fixed power supply of 18 V, one dual range volt meter and important connections are brought out on 4mm sockets.

Easy Demonstration of BJT Switching Action

Engineered for clarity and simplicity, this trainer allows users to observe transistor switching action in real time. With strategically positioned LED indicators and multiple test points, learners can effortlessly monitor circuit response to the included push button control. The robust design ensures consistent performance, making it suitable for repeated demonstrations in educational environments.

Safe and Reliable Laboratory Use

Prioritizing safety, the trainer is equipped with an on-board fuse and operates on low power. Its powder-coated metal chassis and rubber feet provide stability and protection. The built-in regulated adapter ensures a reliable supply for extended lab sessions. This design fosters confidence in both educators and students during practical lessons.

Versatile Educational Tool

The device is lightweight and compact, catering to the demands of modern labs. Its banana sockets and multiple test points offer flexibility for various experimental setups, supporting a broad spectrum of learning objectives. The clear operating manual and included connecting leads enhance its usability, making it a go-to resource for hands-on electronics education.

FAQs of Study of Switching action of a Transistor (BJT):

Q: How does this NPN BJT trainer demonstrate the switching action of a transistor?

A: The trainer showcases the switching behavior of an NPN BJT configured as a switch. By pressing the input push button, users can trigger the transistor, which turns the connected LED ON or OFFvisually demonstrating the concept of digital switching and circuit control in real time.

Q: What educational levels is this trainer suitable for?

A: This equipment is designed for use in schools, colleges, and technical institutes. Its straightforward layout and comprehensive documentation make it accessible for beginners while also being informative for advanced students studying the fundamentals of transistor switching.

Q: When should the multiple on-board test points be used?

A: Multiple test points are provided for practical observation during experiments. Students and instructors can use these points to measure voltages and monitor the transistors behavior in various circuit states, gaining direct insight into the switching process at different locations.

Q: Where can this trainer be used and set up most effectively?

A: Thanks to its compact, tabletop design and anti-slip rubber feet, the trainer is ideal for use on lab desks in educational settings. Its also portable, allowing for easy relocation between different classrooms or lab stations as needed.

Q: What is the correct process for safely operating the trainer?

A: To ensure safe operation, connect the trainer to a 230V AC mains supply using the in-built adapter, then use the provided connecting leads and banana sockets for circuit setup. Always utilize the on-board fuse for protection and consult the operating manual for detailed procedural guidance.

Q: How can this trainer benefit students and educators in electronics courses?

A: The hands-on experience fortified with clear visual indications and accessible test points enhances conceptual understanding of transistor switching. Educators benefit from a durable and reliable device for demonstrations, while students gain direct, practical exposurebridging the gap between theory and real-world application.

Q: What accessories are included, and how do they aid the learning process?

A: The package comprises an operating manual and connecting leads, ensuring users have all the essential tools to conduct experiments efficiently. Detailed documentation and robust hardware foster a structured, engaging, and informative laboratory experience.
