LCR Impedance Circuit Apparatus (AE 250 )

Objective : To calculate AC Power factor of LCR circuit when connected in series & subjected to AC voltage.

Features : Instrument comprises of variable AC Power Supply 0-15 VAC, 2 AC moving coil meters to measure voltage & current, 2 Resistance, 2 Capacitors & 1 Inductance connected inside & connections brought out at terminals

Robust Design for Reliable Laboratory Use

Boasting a premium bakelite panel and a shock-proof, insulating body, this apparatus withstands rigorous use in educational and research labs. Clearly marked test points and high-quality electrical components contribute to both safety and precise operation, making experimental analysis more efficient.

User-Friendly Interface with Multiple Power Options

Equipped with 4mm banana terminals, the apparatus ensures secure and straightforward component connections. Its dual-mode power source supports both 9V DC battery and external adapter, offering uninterrupted use throughout various laboratory settings. The analog scale display keeps measurements clear and immediate.

Wide Application and Flexible Calibration

Factory calibrated for out-of-the-box accuracy, this instrument is user-calibratable for extended reliability. It serves diverse educational and analytical purposes, such as demonstration, teaching, and practical measurement verification. Supplied accessories and an instruction manual enable immediate and confident setup.
