Peak Average Rms Value of a AC Signal

Get a Price/Quote

Product Details:

Display Analog/Graphical
Usage Measurement of AC signal parameters
Power Battery Operated / Mains
Voltage 110 V/220 V Compatible
Product Type Educational Laboratory Instrument
Material Polycarbonate Casing
Design Desktop Mount
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Peak Average Rms Value of a AC Signal Price And Quantity

Minimum Order Quantity 1 Unit

Operating Temperature 0C to 45C
Calibration Factory calibrated
Signal Compatibility Works with sinusoidal and non-sinusoidal AC signals
Peak Measurement Range 0 500 V AC (Peak)
Data Hold Function Yes
Safety Standard IEC 61010-1 compliant
Average Measurement Range 0 330 V AC (Average)
Input Impedance >10 M
RMS Measurement Range 0 350 V AC (RMS)
Sampling Rate 2 Samples per second

Peak Average Rms Value of a AC Signal Product Specifications

Power Battery Operated / Mains
Product Type Educational Laboratory Instrument
Design Desktop Mount
Voltage 110 V/220 V Compatible
Usage Measurement of AC signal parameters
Weight 450 g
Power Source AC/DC Powered
Accuracy 1% of reading
Detector True RMS Analyzer
Display Analog/Graphical
Material Polycarbonate Casing
Dimension (L*W*H) 180 mm x 90 mm x 35 mm

Operating Temperature 0C to 45C
Calibration Factory calibrated
Signal Compatibility Works with sinusoidal and non-sinusoidal AC signals
Peak Measurement Range 0 500 V AC (Peak)
Data Hold Function Yes
Safety Standard IEC 61010-1 compliant
Average Measurement Range 0 330 V AC (Average)
Input Impedance >10 M
RMS Measurement Range 0 350 V AC (RMS)
Sampling Rate 2 Samples per second

Peak Average Rms Value of a AC Signal Trade Information

Supply Ability 5 Unit Per Week
Delivery Time 4-5 Days
Main Domestic Market All India

Product Description

Measurement of Peak, Average & RMS Value of a AC Signal (AE 238 )

Features :Instrument comprises of Step Down Transformer, Circuit Diagram for Peak & Average Value measurement Printed and connections of important points brought out at Sockets/Terminals.

Specification

Country of Origin	Made in India
Model Name/Number	AE 238
Usage/Application	Laboratory
Type	Analog
Power	ac mains
Brand	ASICO

Versatile Signal Measurement

This AC signal analyzer measures peak, average, and RMS values for both sinusoidal and non-sinusoidal signals, making it a flexible tool for a comprehensive range of electrical tasks. With compatibility across common voltage standards (110V/220V) and a wide measurement range, its suitable for varied industrial, commercial, and lab environments.

Engineered for Safety and Accuracy

Featuring high-precision factory calibration and an advanced True RMS Analyzer, this device ensures readings are accurate to within 1%. Safety is prioritized through compliance with IEC 61010-1 standards, a robust polycarbonate casing, and an input impedance exceeding 10 M, reducing risk during operation.

Convenient and Portable Design

Designed in a compact desktop mount form, this meter weighs just 450 g, making it easily portable. The display is graphical and easy to read, while power flexibilityoperating from AC/DC, mains, or batteryadds to its usefulness in various on-site and laboratory settings.

FAQs of Peak Average Rms Value of a AC Signal:

Q: How does the meter measure AC signal parameters?

A: The meter uses a True RMS Analyzer to accurately determine the peak, average, and RMS values of AC signals, regardless of waveform type. It samples at a rate of 2 samples per second and displays results on an analog or graphical display for easy interpretation.

Q: What kinds of AC signals is the device compatible with?

A: This signal analyzer is compatible with both sinusoidal and non-sinusoidal AC waveforms, providing reliable measurements for varied applications such as industrial power, lab experiments, and equipment monitoring.

Q: Where can this device be used effectively?

A: The meter is suitable for use in electrical laboratories, industrial maintenance, manufacturing floors, and educational institutions. Its versatile power options and compliance with international safety standards make it ideal for both field and desktop use in India and abroad.

Q: What is the process for measuring an AC signal using this meter?

A: To measure, connect the signal to the input terminals, select the desired measurement mode (peak, average, or RMS), and read the values directly from the display. The device supports data hold to freeze readings for further analysis.

Q: When should I use the data hold function?

A: The data hold function is useful when you need to capture and retain a displayed value for recording or closer inspection, especially when working in fast-paced testing environments or hard-to-reach places.

Q: What are the benefits of using this True RMS AC signal meter?

A: Key benefits include high measurement accuracy, wide compatibility, multiple power options, and enhanced safety. Its portable design and graphical display improve usability, while IEC 61010-1 compliance ensures safety during operation.
