Clipping and Clamping Circuit Apparatus

Get a Price/Quote

Product Details:

Voltage 012V DC/AC output
Usage Educational laboratory experiments for clipping and clamping circuits
Power 230V AC, 50 Hz (Mains operated)
Display Analog voltmeter
Product Type Clipping and Clamping Circuit Apparatus
Material Powder coated mild steel body, premium FR4 PCB
Design Bench-top enclosed design with test points and sockets
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Clipping and Clamping Circuit Apparatus Price And Quantity

Minimum Order Quantity 1 Unit

Clipping and Clamping Circuit Apparatus Product Specifications

Accuracy High (within 2%)
Dimension (L*W*H) 300 mm x 200 mm x 75 mm
Detector PN junction diodes (Germanium/Silicon)
Design Bench-top enclosed design with test points and sockets
Display Analog voltmeter
Material Powder coated mild steel body, premium FR4 PCB
Product Type Clipping and Clamping Circuit Apparatus
Power 230V AC, 50 Hz (Mains operated)
Weight Approx 2.5 kg
Power Source Electric
Usage Educational laboratory experiments for clipping and clamping circuits
Voltage 012V DC/AC output

Test Points Gold-plated terminals for easy measurements
Safety Features Over-voltage and fuse protection
Operating Temperature 0C to 50C
Circuit Elements Includes diodes, resistors, capacitors, variable voltage supply
Included Components Connecting leads and user manual
Type of Experiments Positive/Negative Clipping, Double-ended Clipping, Positive/Negative Clamping, Biased Clipping
Front Panel Markings Permanent screen printed legends
Output Indicator CRO/oscilloscope terminals provided
Input Waveform Sine, square, or external signal source

Clipping and Clamping Circuit Apparatus Trade Information

Supply Ability 5 Unit Per Week
Delivery Time 4-5 Days
Main Domestic Market All India

Product Description

Clipping & Clamping Circuit Apparatus (AE 252 )

Objective : To study effect of Positive & Negative Clipping & Clamping on Sine Wave.

Features : Instrument comprises of DC Regulated Power Supply 0-3 VDC/150mA, Circuit diagram for Clipping & Clamping Printed, components placed inside & connections brought out at 4mm Sockets.

Comprehensive Laboratory Solution

This bench-top apparatus is tailored specifically for academic use, empowering students and instructors to perform a spectrum of experiments involving signal clipping and clamping. With dedicated test points, premium build quality, and user-friendly instructions, it seamlessly integrates into any laboratory environment, enabling hands-on learning and practical circuit analysis.

Versatile Experiment Support

The unit facilitates multiple types of experiments, including positive and negative clipping, double-ended, biased clipping, and various clamping configurations. Included connecting leads and a detailed user manual allow users to set up and modify circuit parameters efficiently, enhancing experimental flexibility and understanding of waveform shaping principles.

Robust Safety and Durability

Designed with user safety in mind, the apparatus incorporates over-voltage and fuse protection mechanisms. Its enclosure is manufactured from powder-coated mild steel to withstand regular lab use, and permanent front-panel markings ensure measurement accuracy and longevity. Operating efficiently between 0C and 50C, it remains reliable in diverse classroom settings.
