Zener Diode Characteristics and Voltage Stabilization

Get a Price/Quote

Product Details:

Power Depends on Zener rating, typically 0.25W to 5W
Voltage Specified Zener breakdown voltage (Vz), typically 2.7V to 200V
Usage Voltage stabilization and regulation in electronic circuits
Product Type Semiconductor Diode
Material Silicon or occasionally germanium
Design Two terminal P-N junction device
Power Source External DC source as per circuit requirement
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Zener Diode Characteristics and Voltage Stabilization Price And Quantity

Minimum Order Quantity 1 , , Unit

Reverse Leakage Current (Ir) Typically microamperes at rated Vz
Operating Temperature Range -55°C to +150°C (varies by part number)
Maximum Zener Current (Izm) Defined by power rating and Vz; exceeding this may damage the diode
Polarity Operates in reverse-bias for Zener effect
Breakdown Voltage (Vz) Specified for each Zener diode, critical for voltage stabilization
Application Note Widely used in reference voltage circuits, power supply regulation, and surge suppression
Temperature Coefficient Negative for voltages <5.6V, positive for >5.6V
Connection Type Through-hole and SMD variants available
Testing Breakdown characteristics measured using a variable DC supply and milliammeter
Forward Voltage (Vf) Approximately 0.7V for silicon Zener diodes
Dynamic Impedance (Zz) Low, ensuring minimal voltage change for wide current range

Zener Diode Characteristics and Voltage Stabilization Product Specifications

Usage Voltage stabilization and regulation in electronic circuits
Weight Less than 1g (varies by package)
Dimension (L*W*H) Standard diode package dimensions, varies by rating (e.g., DO-41 package: 2.7mm x 2.7mm x 4.6mm)
Power Depends on Zener rating, typically 0.25W to 5W
Voltage Specified Zener breakdown voltage (Vz), typically 2.7V to 200V
Design Two terminal P-N junction device
Product Type Semiconductor Diode
Accuracy High voltage regulation accuracy in specified breakdown voltage range
Power Source External DC source as per circuit requirement
Material Silicon or occasionally germanium

Reverse Leakage Current (Ir) Typically microamperes at rated Vz
Operating Temperature Range -55°C to +150°C (varies by part number)
Maximum Zener Current (Izm) Defined by power rating and Vz; exceeding this may damage the diode
Polarity Operates in reverse-bias for Zener effect
Breakdown Voltage (Vz) Specified for each Zener diode, critical for voltage stabilization
Application Note Widely used in reference voltage circuits, power supply regulation, and surge suppression
Temperature Coefficient Negative for voltages <5.6V, positive for >5.6V
Connection Type Through-hole and SMD variants available
Testing Breakdown characteristics measured using a variable DC supply and milliammeter
Forward Voltage (Vf) Approximately 0.7V for silicon Zener diodes
Dynamic Impedance (Zz) Low, ensuring minimal voltage change for wide current range

Zener Diode Characteristics and Voltage Stabilization Trade Information

Supply Ability 5 , , Unit Per Week
Delivery Time 4-5 Days
Main Domestic Market All India

Product Description

Zener Diode Characteristics & Voltage Stabilization (AE 216 )

Objective : To study Forward & Reverse V-I Characteristics of Zener diode & to study input voltage Vs Output voltage Characteristics & Output voltage Vs Load Characteristics.

Features : Instrument comprises of One DC regulated Power Supply, three round meters to measure input voltage, output voltage & current, one Zener Diode mounted behind the panel, built in load resistence selectable using band switch & Connections brought out at terminals/sockets.

Reliable Voltage Stabilization

Zener diodes are integral in electronic circuits for maintaining a stable voltage despite fluctuations in supply or load conditions. Their defined breakdown voltage (Vz) ensures consistent performance and high accuracy, making them essential for sensitive applications such as reference voltage generation and regulated power supplies.

Broad Operating and Design Flexibility

With a wide operating temperature range (-55C to +150C), multiple power and voltage ratings, and various package types (including DO-41 and SMD), Zener diodes can be easily adapted to different environments and requirements. Their silicon construction guarantees reliability, while models with negative or positive temperature coefficients allow for tailored solutions.

FAQs of Zener Diode Characteristics and Voltage Stabilization:

Q: How does a Zener diode stabilize voltage in electronic circuits?

A: A Zener diode stabilizes voltage by operating in reverse-bias; when the reverse voltage reaches the breakdown voltage (Vz), it maintains a nearly constant voltage, allowing excess current to bypass the load and protect sensitive components from voltage spikes.

Q: What is the typical process for testing Zener diode breakdown voltage?

A: To test breakdown voltage, connect the Zener diode in reverse-bias with a variable DC supply and a milliammeter. Gradually increase voltage until the current sharply risesthis point is the diodes specified Vz. Ensure not to exceed the maximum Zener current (Izm) during this process.

Q: When should I consider using a Zener diode with a positive or negative temperature coefficient?

A: Use Zener diodes with a negative temperature coefficient for voltages below 5.6V, as their breakdown voltage decreases with rising temperature. For voltages above 5.6V, positive coefficients mean Vz increases with temperature; choose as per your applications thermal environment.

Q: Where are Zener diodes commonly used in electronic equipment?

A: Zener diodes are widely used in voltage reference circuits, power supply regulation, surge protection, and as part of overvoltage protection schemes in consumer electronics, industrial controls, and communication devices.

Q: What are the benefits of low dynamic impedance in Zener diodes?

A: Low dynamic impedance (Zz) ensures that the voltage across the Zener diode changes minimally even if the current varies over a wide range, leading to excellent voltage regulation and stable circuit operation.

Q: How do I select the appropriate Zener diode for my power and voltage requirements?

A: Choose a Zener diode with a breakdown voltage (Vz) matching your regulation requirement and ensure the power rating (typically 0.25W5W) exceeds any expected load dissipation. Also, check package type, temperature range, and reverse leakage current for compatibility with your circuit.
