Ripple Factor Apparatus

Get a Price/Quote

Product Details:

Display Digital meter for output reading
Voltage Output up to 30V DC
Power 230 V AC, 50 Hz
Usage Educational laboratory and demonstration purposes
Product Type Ripple Factor Test Apparatus
Material MS Powder Coated Cabinet with durable finish
Design Table-top compact modular design
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Ripple Factor Apparatus Price And Quantity

Minimum Order Quantity 1 Unit

Safety Earth terminal provided for user safety
Enclosure Shockproof insulated body
Input Supply Standard AC mains (230V, 50Hz)
Fuse Protection Built-in for safe operation
Rectifier Types Supports Half Wave, Full Wave, and Bridge Rectifier experiments
Accessories Included Patch cords, Instruction manual
Application Measurement and comparison of AC to DC rectified output
Filter Components Includes capacitor and inductor for filtration study
Cooling Natural air cooled
User Controls Rotary switches for circuit selection
Test Frequency Range Suitable for power frequency (50Hz/60Hz)
Output Terminals Color coded binding posts

Ripple Factor Apparatus Product Specifications

Usage Educational laboratory and demonstration purposes
Power Source Main Supply
Power 230 V AC, 50 Hz
Illuminant Indicator LEDs for status
Product Type Ripple Factor Test Apparatus
Detector Precision rectifier-based
Weight Approx. 6 kg
Voltage Output up to 30V DC
Accuracy High measurement accuracy for ripple factor analysis
Material MS Powder Coated Cabinet with durable finish
Dimension (L*W*H) 340 mm x 220 mm x 150 mm
Display Digital meter for output reading
Design Table-top compact modular design

Safety Earth terminal provided for user safety
Enclosure Shockproof insulated body
Input Supply Standard AC mains (230V, 50Hz)
Fuse Protection Built-in for safe operation
Rectifier Types Supports Half Wave, Full Wave, and Bridge Rectifier experiments
Accessories Included Patch cords, Instruction manual
Application Measurement and comparison of AC to DC rectified output
Filter Components Includes capacitor and inductor for filtration study
Cooling Natural air cooled
User Controls Rotary switches for circuit selection
Test Frequency Range Suitable for power frequency (50Hz/60Hz)
Output Terminals Color coded binding posts

Ripple Factor Apparatus Trade Information

Supply Ability 5 Unit Per Week
Delivery Time 4-5 Days

Product Description

Ripple Factor Apparatus (AE 256 )

Instrument comprises of AC Power Supply, 2 meters to measure Output Voltage & Output current, 4 PN Junction Diodes, Filter Circuit Kit, load Resistances selectable using band switch. One dual range Electronic voltmeter to measure ripple directly.

Explore Multiple Rectifier Types

This apparatus supports half wave, full wave, and bridge rectifier experiments, allowing comprehensive learning and comparative analysis of different AC to DC rectification methods. Users can easily switch between circuit types using rotary switches, making it suitable for a wide variety of educational demonstrations.

Integrated Safety Features

User protection is prioritized with a robust, shockproof insulated MS powder-coated cabinet, built-in fuse, and earth terminal. The apparatus is engineered for safe operation during continuous laboratory usage, while the natural air cooling and clear indicator LEDs ensure reliable and visible status updates.

Precision Measurement Capabilities

The apparatus employs a digital meter for precise output voltage and ripple factor readings, allowing for accurate analysis and data collection. Precision rectifier detection further enhances measurement performance, making it ideal for educational and experimental environments where accuracy is essential.

FAQs of Ripple Factor Apparatus:

Q: How do I use the Ripple Factor Apparatus to study different rectifier circuits?

A: The apparatus comes equipped with rotary switches that allow you to easily select between half wave, full wave, or bridge rectifier circuits. Simply connect the necessary input and output terminals using the supplied patch cords, follow the instruction manual, and observe output readings on the digital meter while experimenting with various circuit types.

Q: What safety features are included in the apparatus for laboratory use?

A: It includes built-in fuse protection, an earth terminal, and a shockproof insulated enclosure to prevent electrical hazards. The natural air cooling system and indicator LEDs further ensure safe and reliable operation during extended use.

Q: When should I use the apparatus filter components during experiments?

A: Use the capacitor and inductor filter components while studying the effect of filtration on rectified outputs. Engaging these components allows you to measure changes in ripple factor, helping you understand how filtration improves the quality of DC output in practical circuit scenarios.

Q: Where can the Ripple Factor Apparatus be utilized most effectively?

A: It is best suited for educational laboratories, technical training institutions, and demonstration setups where clear understanding and comparison of AC to DC conversion methods are required. Its modular compact design makes it convenient for table-top use in classrooms and research labs.

Q: What is the process for measuring and comparing rectified output using this apparatus?

A: Connect the input supply (230V AC, 50Hz) and use patch cords to configure the desired rectifier circuit. Select filter elements as needed, then monitor rectified output voltage and ripple factor on the digital meter. The apparatus supports accurate and repeatable measurements for detailed analysis.

Q: How does the apparatus benefit students or researchers?

A: It offers hands-on experience in analyzing different rectifier types, allows direct observation of ripple factor with and without filtration, and provides highly accurate and safe results. This makes it an invaluable educational resource for understanding the fundamentals of power electronics and AC to DC conversion.
