LCR Q Meter

Get a Price/Quote

Product Details:

Accuracy High precision measurements
Display Type Digital
Features Capacitance Inductance Resistance measurement
Response Time Fast
Test Range Determining L C R values
Operating Voltage Rated voltage
Application Electrical testing and measurement
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

LCR Q Meter Product Specifications

Operating Voltage Rated voltage
Test Range Determining L C R values
Accuracy High precision measurements
Features Capacitance Inductance Resistance measurement
Response Time Fast
Display Type Digital
Resolution High resolution
Test Speed Quick
Machine Weight Approx. 2-3 kg
Usage Measurement of electrical properties
Application Electrical testing and measurement
Control Mode Manual
Mounting Type Benchtop
Power Supply AC power
Interface Type None
Measuring Range Wide measurement range

Product Description

DIGITAL LCR Q METER OR DIGITAL INDUCTANCE METER is Useful for measurement of winding inductance and resistance of coil, transformer, motors, wires, cables, relays, chokes etc. and capacitance of capacitors, wire, cables etc. Superior performance employing LSI IC's. Instant values of D factor measurement, cover wide measurement range 0.1µH - 2000H, 0.1pf - 20000µf, 0.1 - 20M .

Features

** INSTANT VALUE, SIMULTANEOUS 'D' FACTOR MEASUREMENT.
** SUPERIOR PERFORMANCE EMPLOYING LSI IC'S
** WIDE RANGE OF COMPONENT VALUE DISPLAY
** BETTER CALIBRATION ACCURACY 0.5% + 3 COUNT
** AUTOMATIC FREQUENCY SELECTION.
** EXCEPTIONAL STABILITY
