Triode Valve Characteristics Apparatus

Get a Price/Quote

Product Details:

Display Analog meter display
Usage For plotting characteristics of triode valves
Voltage Input: AC 220V 10%, 50 Hz
Power Electronic, fused power supply
Product Type Educational laboratory apparatus
Material Powder-coated metal enclosure and Bakelite panel
Design Bench-top, sturdily built design
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Triode Valve Characteristics Apparatus Price And Quantity

Minimum Order Quantity 1 Unit

Safety Features Fuse and overload protection
Plate Voltage Range 0300V DC variable
Tube Provided Standard triode vacuum tube (included with unit)
Heater Voltage Range 06.3V DC adjustable
Accessories User manual, patch cords
Terminal Connections Color coded, extra insulated
Recommended For Physics and electronic labs, engineering institutions
Measurement Meters Multiple analog meters for voltage and current
Typical Experiments Static characteristics (plate and grid), dynamic transfer characteristics
Grid Voltage Range 0 to 50V DC adjustable

Triode Valve Characteristics Apparatus Product Specifications

Dimension (L*W*H) 430 mm x 160 mm x 340 mm
Weight Approx. 8 kg
Product Type Educational laboratory apparatus
Design Bench-top, sturdily built design
Display Analog meter display
Power Electronic, fused power supply
Material Powder-coated metal enclosure and Bakelite panel
Accuracy High measurement accuracy for voltage and current readings
Power Source Mains powered
Voltage Input: AC 220V 10%, 50 Hz
Usage For plotting characteristics of triode valves
Detector Direct analog meter detector system

Safety Features Fuse and overload protection
Plate Voltage Range 0300V DC variable
Tube Provided Standard triode vacuum tube (included with unit)
Heater Voltage Range 06.3V DC adjustable
Accessories User manual, patch cords
Terminal Connections Color coded, extra insulated
Recommended For Physics and electronic labs, engineering institutions
Measurement Meters Multiple analog meters for voltage and current
Typical Experiments Static characteristics (plate and grid), dynamic transfer characteristics
Grid Voltage Range 0 to 50V DC adjustable

Triode Valve Characteristics Apparatus Trade Information

Supply Ability 5 Unit Per Week
Delivery Time 4-5 Days
Main Export Market(s) Australia, South America, Eastern Europe, Western Europe, Middle East, Asia, Central America, North America, Africa
Main Domestic Market All India

Product Description

Triode Valve Characteristics Apparatus

Triode Valve Characteristics Apparatus with DC Regulated Power Supply (AE 202)

Objective : VI Characteristics of Triode Valve at various Grid voltages.

Features : Instrument comprises of DC Regulated Power Supply 0-300VDC/ 30mA & 0-15VDC/10mA, AC Power Supply 6.3 VAC/1Amp, two round meters for voltage & current measurement.

Explore Triode Characteristics with Precision

This apparatus is engineered to facilitate comprehensive experiments such as measuring the static and dynamic characteristics of triode vacuum tubes. With rapid setup enabled by clear, color-coded connections and multiple analog meters, students and instructors can explore the key parameters of electronic components safely and accurately. Backed by detailed instructions, it offers a thorough laboratory experience for learning and practical skill development.

Advanced Safety and Measurement Features

Safety is prioritized in this unit, with robust fuse and overload protection integrated into its fused electronic power supply. Accurate analog meter displays provide real-time readings for both voltage and current. The external design utilizes powder-coated metal and Bakelite, ensuring both durability and electrical insulation during regular laboratory handling.

FAQs of Triode Valve Characteristics Apparatus:

Q: How do I set up the Triode Valve Characteristics Apparatus for experiments?

A: To set up, connect the included standard triode tube to the color-coded, insulated terminals as described in the user manual. Adjust the heater, plate, and grid voltages via their respective controls, ensuring the values remain within the specified ranges. Patch cords allow for flexible connectivity tailored to specific experimental requirements.

Q: What types of experiments can be performed using this apparatus?

A: The apparatus is suitable for plotting both the static (plate and grid) and dynamic transfer characteristics of triode valves. These experiments are fundamental in physics and electronic lab courses, illustrating how triodes respond to various input voltages and currents.

Q: When should the fuse or overload protection features be checked?

A: The safety features should be checked before each use. If the apparatus fails to power on or displays irregular readings, inspect the fuse and overload protection system as recommended in the user manual. Replacing a blown fuse should only be done when the unit is disconnected from the power supply.

Q: Where is this apparatus typically used?

A: It is recommended for use in physics and electronic laboratories in engineering colleges, technical institutions, and research centers, providing an educational platform for understanding the properties and behaviors of vacuum tubes.

Q: What benefits does the analog meter display offer over digital alternatives?

A: The analog meter display allows users to observe real-time changes in current and voltage, making it easier to track subtle fluctuations during experiments. This fosters a better understanding of electronic principles and enhances practical skills in measurement.

Q: How accurate are the voltage and current measurements on this apparatus?

A: The system is designed for high measurement accuracy, using quality analog meters to ensure voltage and current readings closely match true valuesessential for precise experiment results and effective learning.
