POTENTIAL DIVIDER CIRCUIT KIT

Name: POTENTIAL DIVIDER CIRCUIT KIT
Brand: AMBALA ELECTRONIC INSTRUMENTS
Price: 1000 INR
Availability: InStock

1000 INR/Piece

Get a Price/Quote

Product Details:

Voltage 0-12V DC (Variable)
Usage Educational / Laboratory Experiment
Power Low Power (for Lab Use)
Display Analog Meters (Volt and Ampere)
Product Type Electrical/Electronic Training Kit
Material Metallic body with Bakelite/Plastic panel
Design Front panel schematic with circuit diagram
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

POTENTIAL DIVIDER CIRCUIT KIT Price And Quantity

Price 1000 INR/Piece
Minimum Order Quantity 1 Piece

POTENTIAL DIVIDER CIRCUIT KIT Product Specifications

Display Analog Meters (Volt and Ampere)
Power Source External AC Mains / Built-in Transformer
Accuracy High (as per meter calibration)
Material Metallic body with Bakelite/Plastic panel
Dimension (L*W*H) Approx. 30 cm x 25 cm x 12 cm
Product Type Electrical/Electronic Training Kit
Weight Approx. 2.5 kg
Voltage 0-12V DC (Variable)
Design Front panel schematic with circuit diagram
Power Low Power (for Lab Use)
Usage Educational / Laboratory Experiment
Detector Analog Volt / Amp meter

Panel Markings Clear circuit representation & test points
Terminals 4mm banana sockets for output
Measuring Range (Ammeter) 0-1A
Insulation Protection Fused and earthed
Control ON/OFF toggle switch
Educational Focus Study of Ohm's law, potential division, parallel & series resistance
Measuring Range (Volt Meter) 0-10V
Output Voltage Adjustment Rotary potentiometer provided
Input Supply Voltage 220-240V AC, 50Hz
Circuit Configuration In-built potential divider circuit

POTENTIAL DIVIDER CIRCUIT KIT Trade Information

Main Export Market(s) Asia, Eastern Europe, Middle East, Africa
Main Domestic Market All India

Product Description

POTENTIAL DIVIDER CIRCUIT

SPECIFICATIONS

1. DC REGULATED POWER SUPPLY 0-5V.

2. TWO MOVING COILS VOLTAGE METER 0-5VDC.

3. DECADE VARIABLE RESISTANCE DIAL 0-1000HMS

4. POTENTIAL DIVIDER CIRCUIT PRINTED ON THE FRONT PANEL.

Clear Circuit Representation for Effective Learning

With carefully marked diagrams and easily accessible test points, the Potential Divider Circuit Kit simplifies the study of electrical concepts. These features allow students to visualize circuit layouts and measurement points, supporting a thorough understanding of resistor networks and voltage division principles.

Rotary Potentiometer for Precise Voltage Control

The inclusion of a rotary potentiometer enables users to smoothly vary the output voltage, facilitating experiments that require precise adjustment. Whether you are examining Ohm's Law or exploring series and parallel resistances, this level of control enhances experimental accuracy and repeatability.

Safety and Durability in Laboratory Experiments

Built with a durable metallic body and high-grade insulation, this kit prioritizes user safety. Integrated fusing and reliable earthing ensure protection against electrical risks common in laboratory settings, providing peace of mind for both instructors and students.

FAQ's of POTENTIAL DIVIDER CIRCUIT KIT:

Q: How does the potential divider circuit kit help in understanding Ohm's Law and potential division?

A: The kit allows users to adjust the output voltage using a rotary potentiometer and measure results with analog meters, demonstrating how voltage and current respond as resistance changes. This hands-on approach reinforces theoretical concepts like Ohm's Law and potential division.

Q: What is the recommended process for setting up the potential divider circuit kit in a laboratory?

A: Begin by connecting the kit to a 220-240V AC mains source. Ensure the fuse and earth connections are secure. Use the ON/OFF toggle switch to power up the kit. Connect external components via the 4mm banana sockets, and adjust the voltage as required using the rotary potentiometer.

Q: When should the analog meters be observed during an experiment?

A: It is important to monitor the analog volt and amp meters both before and during experiments to ensure readings remain within the safe measuring range (0-10V for voltage and 0-1A for current), and to accurately document variable outcomes as you adjust resistance or voltage.

Q: Where are the test points and circuit diagram details located on the kit?

A: Test points and the clear circuit representation are all provided on the front panel of the kit. This makes it easy for users to identify measurement locations and understand circuit connections during practical sessions.

Q: What are the benefits of using this kit for educational laboratory experiments?

A: The kit offers high accuracy, user protection, and a simple interface for demonstrating complex electrical concepts, making it ideal for academic use. Its robust construction ensures repeatable experiments and long-lasting reliability, enhancing students' hands-on learning experience.

Q: How can the voltage output be adjusted using this kit?

A: The voltage output can be smoothly adjusted from 0 to 12V DC using the rotary potentiometer. This allows precise control for experiments studying the effects of voltage and current in different resistor configurations.
