Plancks Constant Experiment

Plancks Constant Experiment

Product Details:

  • Usage Laboratory
  • Product Type Constant Experiment
  • Click to view more
X

Plancks Constant Experiment Price And Quantity

  • 1 Unit

Plancks Constant Experiment Product Specifications

  • Constant Experiment
  • Laboratory

Plancks Constant Experiment Trade Information

  • 5 Unit Per Week
  • 4-5 Days
  • Australia North America South America Eastern Europe Western Europe Middle East Africa Asia Central America
  • All India

Product Description

Determination Of Planck's Constant And Work Function Of Materials By Photoelectric Effect.

The Apparatus Consist Of The Following :

  • Photo Sensitive Device : Vacuum Photo Tube.
  • Light Source : Halogen Tungsten Lamp 12v/35w.
  • Colour Filters : 635nm, 570nm, 540nm, 500nm & 460nm.

Accelerating Voltage : Regulated Voltage Power Supply

  • Output : (+-)5V Continuously Variable Through Multi-Turn Pot
  • Display: 3 1/2 Digit 7-Segment Led
  • Accuracy: (+-)0.2%



Current Detecting Unit : Digital Nanoammeter It Is High Stability Low Current Measuring Instrument:

  • Range : 1000 Microa, 100 Microa, 10 Microa & 1 Microa With 100% Over Ranging Facility
  • Resolution : 1na At 1 Microa Range
  • Display: 3 1/2 Digit 7-Segment Led
  • Accuracy: (+-)0.20

Power Requirement : 220v (+-) 10%, 50hz

Optical Bench : The Light Source Can Be Moved Along It To Adjust The Distance Between Light Source And Phototube. Scale Length Is 400 Mm. A Drawtube Is Provided To Install Colour Filters, A Focus Lense Is Fixed In The Back End.
