Load Cell Trainer

Get a Price/Quote

Product Details:

Voltage 220V AC, 50 Hz
Display 4 Digit LED Digital Display
Usage Educational/Training in Measurement Labs
Power 5 W
Product Type Load Cell Trainer
Material Mild Steel (Powder Coated)
Design Table Top Compact Design
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Load Cell Trainer Price And Quantity

Minimum Order Quantity 1 Unit

Output Sensitivity 2.0 mV/V
Operation Temperature 0°C to 50°C
Excitation Voltage 10V DC
Calibration Provided with Standard Weights
Accessories Included Instruction Manual, Test Loads
Interface Banana Terminals for Signal Connection
Input Type Single Load Cell
Resolution 0.01 kg
Load Cell Capacity 5 kg
Overload Protection 120% of Rated Capacity

Load Cell Trainer Product Specifications

Voltage 220V AC, 50 Hz
Weight Approx. 3.5 Kg
Material Mild Steel (Powder Coated)
Charging Time Not Applicable (Mains Powered)
Detector Strain Gauge Type
Accuracy 0.02% F.S.
Power 5 W
Design Table Top Compact Design
Usage Educational/Training in Measurement Labs
Display 4 Digit LED Digital Display
Dimension (L*W*H) 325 x 250 x 100 mm
Power Source Electric
Product Type Load Cell Trainer

Output Sensitivity 2.0 mV/V
Operation Temperature 0°C to 50°C
Excitation Voltage 10V DC
Calibration Provided with Standard Weights
Accessories Included Instruction Manual, Test Loads
Interface Banana Terminals for Signal Connection
Input Type Single Load Cell
Resolution 0.01 kg
Load Cell Capacity 5 kg
Overload Protection 120% of Rated Capacity

Load Cell Trainer Trade Information

Supply Ability 5 Unit Per Week
Delivery Time 4-5 Days

Product Description

Load Cell Trainer

Specifications:

Study the principle/working of load cell & Its applications to measuring load

Bridge made up of 4 strain gauges mounted on a specially alloy materials type load cell

Built in excitation voltage for the bridge

3.5 digit SSD for direct reading stain in Kg.

Built in highly sensitive signal amplifier.

Multi turn potentiometer for zero adjustment.

Different loads provided for building up of load.

Test pins for monitoring at all stages.

Interconnection: 2/4mm banana sockets

DC Supply: Built in lC regulated power supplies

220V ±10%, 50Hz mains operated

Standard Accessories: Users Manual with patch cords

Enclosed in an attractive ABS plastic cabinet with cover

Precise Measurement and Training Benefits

This Load Cell Trainer enables students and laboratory professionals to learn the fundamentals of load cell measurement and calibration. With built-in overload protection and a user-friendly LED display, it ensures safe and reliable operations. The high accuracy and fine resolution allow learners to explore measurement principles in detail, making it ideal for practical demonstrations and hands-on experiments.

Robust Design and Ease of Use

Built with a sturdy mild steel, powder-coated enclosure, this trainer is compact yet durable. It is engineered for table-top use, allowing straightforward integration into most lab setups. The inclusion of banana terminals simplifies connections, while the supplied instruction manual and test loads support seamless setup and operation. The trainers design is tailored for the educational sector but also serves well for practical training in measurement techniques.

FAQs of Load Cell Trainer:

Q: How is the Load Cell Trainer used in an educational laboratory?

A: The Load Cell Trainer is mainly used to teach and demonstrate the principles of force measurement and calibration in educational measurement labs. Students can observe real-time readings on the LED display and use standard weights provided to conduct hands-on experiments in a controlled environment.

Q: What is the benefit of the trainers overload protection feature?

A: The overload protection, rated at 120% of the load cells 5 kg capacity, safeguards the equipment from accidental overloading, which helps maintain its accuracy and extend the lifespan of the device.

Q: What is the calibration process for this Load Cell Trainer?

A: Calibration is performed using the standard test weights provided. The process involves applying known loads sequentially and confirming that the LED display matches the applied weight, adjusting as necessary to maintain accuracy.

Q: Where should this trainer be operated for optimal performance?

A: The trainer should be used indoors, within a temperature range of 0C to 50C, on a stable tabletop surface. Proper placement ensures reliable results and protects the devices internal components.

Q: When does the trainer need maintenance or recalibration?

A: Routine recalibration should be performed before each major training session or semester, especially after moving the device. Visual inspection of connectors and terminals is recommended periodically to ensure lasting performance.

Q: What accessories are included with the Load Cell Trainer upon purchase?

A: The trainer is supplied with an instruction manual and test loads, providing all the essential tools for setup, calibration, and operation right out of the box.

Q: How does the resolution and accuracy enhance measurement experiments?

A: With a resolution of 0.01 kg and an accuracy of 0.02% F.S., the trainer allows for highly precise measurements, enabling users to detect small weight changes and perform detailed analysis during experiments.
